EtherSound Card, 16 Channel
16-Channel EtherSound network I/O card, two EtherCon network connectors, 9 pin HA Remote and two RJ45 cascade connectors. Use with up to 3 MY16EX cards to increase I/O capability to 64 channels.
Plug-in, expandable EtherSound Audio Networking
Yamaha has expanded its lineup of mini-YGDAI format cards with the introduction of MY16-ES64 EtherSound Interface card and MY16-EX expansion card.
EtherSound is the digital audio and control transfer protocol of choice for many modern live sound applications. Now with a single Yamaha MY16-ES64 card you can add 16channels of bidirectional EtherSound connectivity to a range of Yamaha professional audio devices that accept mini-YGDAI expansion cards. Simply add one, two or three MY16-EX expansion cards to the core MY16-ES64 card to increase the EtherSound channel capacity to 32, 48 or 64 channels.
• 24bit resolution,16-in/16-out EtherSound (ES100) interface (8-in/8-out at 96kHz)
• Expandable to up to 64-in/64-out with MY16-EX expansion cards
• 2x etherCON CAT5 connectors for EtherSound I/O, 1x D-sub 9 pin connector for RS232-C, 2x RJ-45 connectors for MY16-EX connection
• Remote setup, patching and monitoring by AVS Monitor
Mini-YGDAI cards make it easy to add I/O in a wide variety of audio and network formats to Yamaha digital mixing consoles, processors, and power amps that are equipped with compatible card slots. Mini-YGDAI cards can give your system the most up-to-date capabilities for any application.
| General Specifications | |
|---|---|
| Channel Count | 16IN / 16OUT |
| Format | EtherSound |
| Resolution | 24 bit |
| Connector | 2x EtherCon (for EtherSound), 2x RJ-45 (for MY16-EX), D-sub 9-pin (for HA remote) |
