Wolfmix W1 MK2 DMX Lighting Controller

Standalone (no computer required)

• Compatible with any DMX device
• Up to 4 DMX universes (2048 channels. Add-on required for U3+4)*
• Up to 680 spotlights & beams
• Up to 50 fixture types
• Up to 5000 fixture properties (colour/gobo etc… )
• 8 device groups
• 6 projects
• 15000+ available fixtures (3500+ on the controller)
• DMX address, fixture order and group settings
• Use as DMX splitter with DMX universe mapping

Palettes & FX

• Colour FX module with 8 effect types & 16 definable colours
• Move FX module with 8 effect types
• Beam FX module with 8 effect types
• 6 flash buttons for controlling special FX, strobe, blinder, speed, blackout & smoke
• Static colour palette with 10 user-defined colours per group & colour gradient control
• Static position palette with 5 user-defined positions per group with fade & fanning
• Gobo palette with 5 customisable gobos per group
• 20 nameable live edit buttons with flash trigger mode and ‘park’ function
• 100 nameable presets to save snapshots with hold and fade timings
• Preset playback cue list – all presets or per page of 20 presets

Control & synchronisation

• Group and master dimming with encoder acceleration
• Group FLASH, FULL and Blackout
• 16-bit pan/tilt control
• Multi-beam LED bar control
• FX music pulse synchronisation from microphone or line-in
• FX BPM synchronisation with Ableton Link, OS2L or BPM TAP
• Effect speed, phase, sequence, size, fade, fan & flick
• Live control of the Move FX registration point
• Global FX speed and freeze control
• Map DMX IN with group dimmer and patch to output channels (add-on required)*
• WLINK – sync with another Wolfmix controller (add-on required)*
• Built-in tools
• Fixture Builder
• Fixture calibration tool to limit the range of moving fixtures
• X-Y touch-controlled positioning grid
• RGBW touch-controlled colour picker
• 8-step real-time sequencer for creating beam and move FX
• Live view of DMX levels with override of default values and DMX channel tester
• Beam editor for overwriting the min and max values for the generated effects
