PAP-1000 ojačevalnik 100V, 1000W

Dodatne Informacije

• Power supply: 230 V AC, 50 Hz
• Power consumption: 2000,00 W
• Output power: 1000 W RMS
• Power connection: Fixed power supply cord with safety plug
• Frequency range: 80 – 16000 Hz
• S/N ratio: >90 dB line
• THD: <0,5 % at 1 kHz
• Cooling: 2 x cooling fan , Air flow from front to rear
• Impedance: 4-16 ohms; Public address systems 100V; Public address systems 70V
• Circuitry: Class AB
• Controls: Softstart; overheat; overload; short-circuit; DC voltage
• Status LED: Signal, power, fault, clip
• Connections: Input: line via 1 x 6.3 mm jack socket (mono) mounting version
• Input: line via 1 x 3-pin XLR 0,3 V
• Output: line via 1 x 6.3 mm jack socket (mono) mounting version
• Output: line via 1 x 3-pin XLR
• Channels: Master output: mono, channel control via Rotary dial
• Material: Metal
• Color: Black
• Housing design: (19″) 48.3 cm rack installation 3 U
• Dimensions: Width: 48,3 cm
• Depth: 54,7 cm
• Height: 13,35 cm
• Weight: 24,40 kg
