DAP IMIX-6.2 7 kanalna mešalna miza, Bluetooth

Tehnični podatki

Inputs:

• Mono Inputs: 2 (3-pin XLR, TS unbalanced 6.3 mm connectors, 10 dB gain range).
• Stereo Inputs: 5 (RCA connectors).

Outputs:

• Main Outputs: 2 (3-pin XLR connectors).
• Zone Outputs: 2 (3-pin XLR and RCA connectors).
• Headphone Output: 1 (TS balanced 6.3 mm connector).
• Record Output: 1 (RCA connector, 10 Ω impedance).

Audio Specifications:

• THD Level: < 0.03%.
• Frequency Response: 20 Hz – 30,000 Hz.
• Parametric Channel Equalizer: 3 bands with 12 dB gain range.
• Input Channel Sweep Frequencies: 100 Hz, 2500 Hz, 10,000 Hz.
• Built-in FX: Reverb.

Wireless:

• Bluetooth Version: 5.0.

Indicators:

• LED indicators for BT Pairing, Limit, Mute, Output Level, and PFL.

Power:

• Power Supply: 100-240 V AC, 50/60 Hz (via power adapter).
• Output Voltage: 15 V DC.
• Power Consumption: 15 W.

Mechanical Specifications:

• Dimensions: 88.9 mm (H) x 482 mm (W) x 129 mm (D).
• Weight: 2.6 kg.
• Housing: Metal, 19″ rack-mountable (2U size).
• IP Rating: IP20 (indoor use only).

Thermal Specifications:

• Operating Temperature: -10 °C to 40 °C.
