28.7% -

SA-440/SW stereo ojačevalnik, 2 x 100W

199,00

2 x 100W Stereo ojačevalnik z mikrofonskimi vhodi. Idealen za fitnes dvorane, plesne studie, gostinske lokale

Opis

SA-440/SW Stereo ojačevalnik 2 x 100W

Koncept delovanja, ki je enostaven za uporabo in jasno urejene funkcije. Dva stereo linijska vira in dva mono mikrofonska vira se lahko brez težav mešata skupaj. Vsak vhodni kanal ima nadzor tona.
Glavne izhodne nivoje je mogoče vnaprej nastaviti z maximalno glasnostjo.

Tiho delovanje zaradi koncepta hlajenja brez ventilatorja
2 stereo linijska vhoda
2 uravnotežena mikrofonska vhoda
Vzporedni stereo linijski vhod na sprednji plošči
3 sistemska kontrola barve tona Hi / Mid / Low za vsak mikrofonski vhod
Skupna kontrola Ho/ Low za dva linijska vhoda
Glavno maximalno glasnost je možno nastavit
Nastavljiv izhod za slušalke ali dodatno glasnost
Stereo izhod za dodatni ojačevalnik

Navodila za uporabo.PDF
Stran v katalogu.PDF
Izjava o skladnosti izdelka.PDF

Dodatne Informacije

Peak output power 2 x 100 W
Power rating 100 W
Power rating at 4 Ω 2 x 50 W
Power rating at 8 Ω 2 x 30 W
Channels 2
Inputs 125 mV/10 kΩ (line)

1.3 mV/600 Ω (mic)
Frequency range 20-20,000 Hz
Equalizer bass ± 12 dB/30 Hz
Equalizer midrange ± 12 dB/1 kHz (voice only)
Equalizer treble ± 12 dB/12 kHz
S/N ratio > 60 dB
Mains voltage ~ 230 V
Mains frequency 50 Hz
Power consumption, operation 220 VA
Admiss. ambient temp. 0-40 °C
Width 432 mm
Height 52 mm
Depth 275 mm
Rack units, RU 1
Weight 3.5 kg
Connections 3 x RCA L/R (line),

2 x 6.3 mm jack, bal. (mic),

2 x RCA L/R (master),

1 x RCA L/R (rec.),

1 x plug-in screw terminal (mute),

4 x spring-load. speaker term. (speakers)
Packing dimensions (W x H x L) 0.34 x 0.11 x 0.46 m
Gross weight 5.22 kg
Net weight 4.7 kg

Peak output power 2 x 100 W
Power rating 100 W
Power rating at 4 Ω 2 x 50 W
Power rating at 8 Ω 2 x 30 W
Channels 2
Inputs 125 mV/10 kΩ (line)

1.3 mV/600 Ω (mic)
Frequency range 20-20,000 Hz
Equalizer bass ± 12 dB/30 Hz
Equalizer midrange ± 12 dB/1 kHz (voice only)
Equalizer treble ± 12 dB/12 kHz
S/N ratio > 60 dB
Mains voltage ~ 230 V
Mains frequency 50 Hz
Power consumption, operation 220 VA
Admiss. ambient temp. 0-40 °C
Width 432 mm
Height 52 mm
Depth 275 mm
Rack units, RU 1
Weight 3.5 kg
Connections 3 x RCA L/R (line),

2 x 6.3 mm jack, bal. (mic),

2 x RCA L/R (master),

1 x RCA L/R (rec.),

1 x plug-in screw terminal (mute),

4 x spring-load. speaker term. (speakers)
Packing dimensions (W x H x L) 0.34 x 0.11 x 0.46 m
Gross weight 5.22 kg
Net weight 4.7 kg
