Opis
• Conductor drains Ø mm: OFC 28 x 0,10
• Conductor insulation: PE red+blue
• Conductor insulation: 1,5 (Ø in mm)
• Filler material: paper + cotton yarn
• 1st shield: OFC twisted 83 x 0,12
• 2nd shield: –
• Outer isolation: PVC black, blue, red,
yellow, green
• Outer isolation Ø in mm: 6
Conductor resistance: 80 Ohm/Km
Shield resistance: 25 Ohm/Km
Capacity Inner conductor: 60 pF/m
Cap. Inner conduct. Shield
/ Inner conduct.: 78 pF/m
Working temperature min. / max.: -20~60 °C
Working Voltage overflash: 30V
Nom Impedance: 110 Ohm
