LD Systems VIBZ 8 DC – 8 kanalna mešalna miza z DFX efekti in kompresorjem

LD Systems VIBZ 8 DC – 8 kanalna kompaktna mešalna miza s štirimi XLR mikrofonskimi vhodi z visoko kakovostnim predojačevalnikom, mono–združljivost stereo kanalov, integriranim kompresorjem ter 100 digitalnimi efekti s 24–bitno ločljivostjo.

8-channel mixer with 100 digital effects presets
4 microphone channels and 3 stereo line inputs
Effective 3-band EQ
Sliding adjustable compressor
Master, Monitor and headphone outputs
Securely fastening external power supply

Garancija na: LD Systems, Gravity, Cameo, Palmer produkte kupljene v katerikoli trgovini v Sloveniji ali drugje v EU.
Tel: 02 / 776 10 51

Dodatne Informacije

Dodatne informacije o izdelku

Product number:	LDVIBZ8DC
Product type:	Mixer
Type:	Live
Channels:	8
Mono Channels:
Mono Mic and Line Input Channels:	4
Mono Mic input connectors:	XLR, 6.3 mm TRS
Channel Inserts:	2
Channel Insert Connectors:	6.3 mm TRS
Mono Mic Input Type:	electronically balanced
Mono Mic Input Frequency Range:	10 – 45000Hz
Amplification Range mono Mic Input:	0 – 50dB
Mono Mic Input Input THD-N:	0.0058%
Mono Mic Input Impedance:	4kOhm(s)
Mono Mic Input S/N Ratio:	113dB
Mono Line Input Type:	electronically balanced
Mono Line Input Frequency Range:	10 – 45000Hz
Amplification Range mono Line Input:	0 – 50dB
Mono Line Input Input THD-N:	0.0045 %
Mono Line Input Impedance:	21kOhm(s)
Mono Line Input S/N Ratio:	113dB
Mono Channel Equalizer High:	+/- 15 dB @ 12000 Hz
Mono Channel Equalizer Mid:	+/- 15 dB @ 2500 Hz
Mono Channel Equalizer Low:	+/- 15 dB @ 80 Hz
Controls Mono Mic and Line Input Channels:	Low Cut (75 Hz), Gain, pan, Channel Volume, Compressor (channel 1+2), AUX (DFX) Post, 3-band EQ (High, Mid, Low)
Phantom power:	48 V DC switchable
Stereo Channels:
Stereo Line Input Channels:	3
Stereo Line Input Connectors:	6.3 mm TRS
Stereo Line Input Type:	unbalanced
Stereo Line Input Frequency Range:	10 – 45000Hz
Amplification Range stereo Line Input:	0 – 50dB
Stereo Line Input Input THD-N:	0.0045 %
Stereo Line Input Impedance:	3,7kOhm(s)
Stereo Line Input S/N Ratio:	116dB
Stereo channel equalizer treble:	+/- 15 dB @ 12000 Hz
Stereo channel equalizer mids:	+/- 15 dB @ 2500 Hz
Stereo channel equalizer bass:	+/- 15 dB @ 80 Hz
Controls Stereo Line Input Channels:	AUX (DFX) Post, Balance, 2-band EQ (High,Low), Gain, Channel Volume, Low Cut, 3-band EQ (High, Mid, Low)
Main Section:
AUX / Effects Send Channels:	1
AUX / Effects Send Connectors:	6.3 mm stereo jack unbalanced
Stereo AUX Return Channels:	1 x stereo
Stereo AUX Return Connectors:	2 x 6.3 mm TRS
Stereo Tape Out Channel:	1 x stereo
Stereo Tape Out Connectors:	2 x RCA (Cinch)
Stereo Tape In Channel:	1 x stereo
Stereo Tape In Connenctors:	2 x RCA (Cinch)
Unbalanced stereo Main Outputs:	1
Unbalanced stereo Main Output Connections:	6.3 mm TRS
Unbalanced Stereo Main Out Impedance:	120Ohm(s)
Max. Unbalanced Stereo Main Out Level:	20dBu
Stereo Control Room Out:	1
Stereo Control Room Out Connectors:	6.3 mm TRS
Headphones ouput:	1
Headphones outputs:	6.3 mm TRS
Digital Effects Processor:	Yes, 24-bit AD/DA Resolution
Number of Presets:	100
Footswitch Connector DFX Mute:	6.3 mm TRS
Main section controls:	DFX To Main Volume, DFX Presets, DFX Mute Schalter, Master Volume, Stereo Return Volume, Phantom Power, Phones / Control Room Volume
Indicators:	Channel Peak, Power, 8-segment Level Meter, DFX Peak / Mute, Phantom Power
Operating voltage:	18 V AC – 1 A, External PSU
Width:	265mm
Height:	78mm
Depth:	352mm
Weight:	2.2kg
