DAP CA-4500 DSP, 4-kanalni ojačevalec 4x 500 W

Dodatne Informacije

• Outputs
• 2 ohms Stable No
• Output per Channel into 8 ohms at 1 kHz 250 W
• Output per Channel into 4 ohms at 1 kHz 500 W
• Bridge Output into 8 ohms at 1 kHz 1000 W
• Output per Channel into 8 ohms from 20 Hz – 20
• kHz
• 250 W
• Output per Channel into 4 ohms from 20 Hz – 20
• kHz
• 500 W
• Bridge Output 8 ohms from 20 Hz – 20 kHz 1000 W
• Bridge Output 100 V 1000 W
• Output Channels 4
• Output Gain 34 dB
• Output Mode 4-channel, Bridge, Mono, Stereo
• Output Connector Speaker Connector 4 pole

• Inputs
• Mono Inputs 4
• Mono Input Connector 3-pin XLR
• Mono Input Impedance 20000 Ω
• Unbalanced Mono Input Sensitivity 1 dBv
• Audio Specifications
• THD Level < 0.15 %
• Signal-to-noise Ratio > 96 dB
• AD/DA Convertor Sample Rate 96 kHz
• Audio Latency 1.5 ms
• Slew Rate 25 V/μs
• Amp Technology Class D
• Damping Factor 180 :1
• Crosstalk 60 dBu
• Frequency Response Minimum 20 Hz
• Frequency Response Maximum 20000 Hz
• Software Specifications
• Supported Operating Systems Windows

• Sound Editing
• Parametric Input Equalizer 8 Bands
• Parametric Output Equalizer 8 Bands
• Input Equalizer Types Bell, High Shelf, Low Shelf, Notch
• Output Equalizer Types High Shelf 6, High Shelf 12, Low Shelf 6, Low
• Shelf 12
• Crossover Filter Types Bessel, Butterworth, Linkwitz Riley
• Crossover Slopes 6, 12, 18, 24, 30, 36, 42, 48 dB
• Dynamics Processing Compressor, Gate, Limiter
• Phase Reverse Yes

• Internal Storage
• User Presets Yes

• Control and Programming
• Control Mode Manual, PC Software
• Display OLED

• Electrical Specifications and Connections
• Power Supply 220-240 V AC 50 Hz
• SMPS Yes
• Power Consumption 1741 W
• Fuse 10 A
• Power Connector In IEC
• Data Connector In USB

• Mechanical Specifications
• Amplifier Airflow Front to back
• Amplifier Cooling Radial Fan
• Height (mm) 44 mm
• Width (mm) 483 mm
• Length (mm) 285 mm
• Installation Depth (Excl. Connector) 285 mm
• Flightcase Size 19″
• Weight 5.9 kg
• IP Rating IP20 (indoor use only)
• Product Properties
• Handles No
• Electronic Protection Clip limiter (fixed), DC voltage, Overheat,
• Overload, Short circuit, Softstart, Thermal
