DAP-Audio HP-900 Ojačevalnik 2x450W

Dodatne Informacije

• Output per Channel into 8 ohms at 1 kHz 350 W
• Output per Channel into 4 ohms at 1 kHz 450 W
• Bridge Output into 8 ohms at 1 kHz 900 W
• Output per Channel into 8 ohms from 20 Hz – 20 kHz 350 W
• Output per Channel into 4 ohms from 20 Hz – 20 kHz 450 W
• Bridge Output 8 ohms from 20 Hz – 20 kHz 900 W
• Output Mode Bridge, Parallel, Stereo
• Output Connector Speaker Connector 4 pole

Inputs

• Mono Inputs 2
• Mono Input Connector 3-pin XLR
• Mono Input Impedance 20000 Ω
• Balanced Mono Input Sensitivity 1 dBu

Audio Specifications

• THD Level < 0.5 %
• Signal-to-noise Ratio > 100 dB
• Slew Rate 13 V/μs
• Amp Technology Class AB
• Damping Factor 100 :1
• Crosstalk 75 dBu
• Frequency Response Minimum 10 Hz
• Frequency Response Maximum 20000 Hz

Electrical Specifications and Connections

• Power Supply 220-240 V AC 50 Hz
• SMPS No
• Power Consumption 1100 W
• Fuse 6 A
• Power Connector In IEC

Mechanical Specifications

• Amplifier Airflow Front to back
• Amplifier Cooling Axial fan
• Height (mm) 88 mm
• Width (mm) 483 mm
• Depth (mm) 310 mm
• Installation Depth (Excl. Connector) 310 mm
• Flightcase Size 19″
• Rack Units 2 U
• Housing Metal
• Colour Gray
• Finish Powder Coating
• Weight 10.6 kg
• IP Rating IP20 (indoor use only)

Product Properties

• Handles No
• Electronic Protection Clip limiter (fixed), DC voltage, Overheat,
• Overload, Short circuit, Softstart, Thermal
• LED Indicators Clip, Protect, Signal

Included Items

• Included Cables IEC cable
• Included Accessories Rubber feet
